Product Overview
Filtered Boiling
Instant boiling water, ideal for tea, coffee, and quick cooking.
Filtered Cold
Filtered cold water straight from your tap for drinking or cooking.
Normal Hot
Standard hot water for daily kitchen tasks like washing dishes or preparing food.
Normal Cold
Regular cold water for all kitchen needs, ensuring full tap functionality.
Description
Digital 4 in 1 Instant Boiling and Filtered Water Tap
Model: Aquatap Classic Digital | C Shape | Finish: Gold
The Digital Aquatap Classic is a versatile, multifunctional tap that provides instant access to four distinct water dispensing options. Operated through a digital touch pad and handle, this elegant tap combines functionality and style for your kitchen.
Included Components
- Digital Aquatap Classic C Shape Tap: 4-in-1 functionality in a gold finish.
- 2.4L Boiler Unit: Compact and energy-efficient.
- Single Water Filter Provides filtered water free from impurities.
- Pressure Reducing Valve: Set to 3 bar for safe operation.
Key features and functionality:
4-in-1 Functionality
- Filtered Boiling Water (98°C)
- Instantly access boiling water for tea, coffee, or cooking.
- Adjustable temperature settings for customised use.
- Filtered Ambient Water
- Crisp, clean water filtered to remove impurities.
- Unfiltered Hot Water
- Access your household’s hot water supply directly.
- Unfiltered Ambient Water
- Dispenses room-temperature water directly from your cold water supply.
Key Features:
2.4-Litre Boiler Unit – Energy Efficient
- Heats water to 98°C quickly, with adjustable temperature options.
- Supplies instant hot water for 8-10 mugs, saving time in the kitchen.
Single Filtering System
- Nano phosphate filter prevents limescale build-up and removes bacteria, chlorine, and other impurities.
Design and Installation
- Compact boiling water tank for easier installation and maximised cupboard space.
- Tap features 180-degree limited rotation for flexibility and reach.
Safety Features
- Digital Touch Lock: Prevents accidental use of boiling water.
- Boiling Water Function: Operates only while the red button is held; stops immediately when released.
- Insulated Spout: Remains cool to the touch for added safety.
Warranty
- Tap: 5 years.
- Boiler Unit: 2 years.
Maintenance Note: Filters must be replaced every 6 months to maintain the warranty and ensure optimal performance.
WARNING – PLEASE NOTE THAT THE CUPBOARD MUST BE VENTILATED TO ALLOW SUFFICIENT AIRFLOW TO STOP THE CHILLER OVERSHEATING.
Specifications
4-in-1 Tap Specification:
- Mounting: Deck or sink mount (35mm hole required)
- Tap Clearance: Minimum distance from the centre of the tap hole to the wall is 80 mm
- Spout Insulation: Keeps the spout cool to touch while dispensing boiling water
- Cartridges: Quarter turn ceramic cartridges for ease of use and long service life
- Spout Features: 180-degree swivel spout with aerator fitting for maximum flexibility and good water flow
- Levers:
- Right-hand side Hot/Cold water lever – easy to use single lever
- Digital Touch Pad:
- WHITE LED: Hold 3s to unlock water functions. Prevent s accidental activation of the boiling water function
- RED LED: Hold to dispense boiling water.
- BLUE LED: Tap to start/stop filtered ambient water.
- Additional Features: Opposite twist for cold filtered water
- Installation: Flexible connecting hoses and tap fixing kit included. 3 electric sockets required: Boiler, Chiller and Junction Box.
- Guarantee: 5 years
Tap Dimensions:
- Height: 397.3mm
- Spout Reach: 200mm
- Spout Width: 28mm
- Tap Hole: 35mm
————————————
2.4 litre Boiler Specification:
- Display: Front view digital touch screen – easy to read and use
- Installation: Simple and quick, normally takes no more than one hour depending on existing plumbing
- Capacity: 2.4 litres (sufficient for 7-8 cups of tea or coffee)
- Water Pressure: Minimum 1.5 bar, maximum 5.0 bar
- Temperature Range: Pre-set 55°C to 98°C with thermostat accuracy to plus/minus 0.5°C
- Heat Up Time: Approximately 8 minutes for cold water
- Materials:
- Outer Casing: Powder coated mild steel
- Inner Tank: Stainless steel
- Insulation: Latest technology for maximum energy efficiency
- Guarantee: Tank has a 2 year guarantee
Boiler Dimensions:
- Height: 262mm
- Width: 196mm
- Depth: 196mm
Boiler Electrical Data:
- Standard 13 amp detachable cable
- Voltage: 220-240 volt
- Power Rating: 1.5kw
————————————
Single Filter System Specification:
- Function: Filters water, protects tank from limescale build up, and improves boiling water taste
- Filters: Nano phosphate filter to prevent limescale in the tank. Removes bacteria, chlorine, and other particles
- Installation: Fits neatly under the sink with easy installation
- Replacement Cycle: Estimated every 6 months
- Filter Housing Dimensions:
- Height: 295mm
- Width: 80mm
What do our filters remove?
- Chlorine: 99.5%
- Trichloromethane: 95.78%
- Lead: 98.4-99.2%
- Arsenic: 97.8%-86.7%
- Iron: 99.5%
- Manganese: 98.7%
*Free Delivery is offered to UK Mainland destinations only. We will add a delivery charge to below destinations:
- Scottish Islands
- Scottish Highlands
- Northern Ireland
- Isle of Man, Jersey and Guernsey
Installation:
- Indoor use only.
- Must not be installed in areas where water jets could be used.
- Allow at least 24 hours after transportation before turning on the unit to ensure proper fluid redistribution.
- A tilt of less than 2° is required for safe operation.
Maintenance:
- Replace the filter cartridge every 6 months to prevent limescale build-up.
- The unit must not be cleaned with water jets.
Regularly inspect for leaks or damage. If found, isolate the unit, drain, and contact the manufacturer.
Installation Guide & Diagrams
Product Enquiry
Contact Us for Comprehensive Information on Features, Specifications, and Technical Details.
Reviews
Digital Aquatap FIZZ features electronic Touch Pad on the tap for easy and intuitive operation
WHITE Led: Lock
RED LED: FILTERED BOILING WATER
BLUE LED: FILTERED AMBIENT WATER
